ASTM A105 STAINLESS STEEL SP97 THREADOLET
- Payment Type:
- L/C, T/T
- Incoterm:
- FOB, CFR, CIF
- Min. Order:
- 10 Piece/Pieces
- Min. Order:
- 10 Piece/Pieces
- Delivery Time:
- 20 Days
- Transportation:
- Ocean, Land, Air
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Cangzhou,China |
|---|---|
| Productivity: | 1000pcs/month |
| Supply Ability: | 1000pcs/month |
| Payment Type: | L/C,T/T |
| Incoterm: | FOB,CFR,CIF |
| Certificate: | CE/API/ISO |
| Transportation: | Ocean,Land,Air |
Bangdong provide all kinds of olet. include threadolet, weldolet, sockolet. elbolet, latrolet, weepolet and so on .
Material: A105
Key Specifications / Features
Type: Weldolet
Wall Thickness: XXS
Size: 3 Inch X 2.5 Inch
Standard: MSS SP-97
Ends: BW Ends
| Chemical Composition and Mechanical Property For ASTM A105 | |||||||||||||||
| Steel Grade | Chemical Composition | Hardness | Mechanical performance | ||||||||||||
| C(Max) | Mn | P(Max) | S(Max) | Si | Cu(Max) | Ni(Max) | Cr(Max) | Mo(Max) | V(Max) | HB, max |
Tensile strength (Min) |
Yield Strength (Min) |
|||
| psi | Mpa | psi | Mpa | ||||||||||||
| A105 | 0.35 | 0.6-1.05 | 0.035 | 0.04 | 0.1-0.35 | 0.4 | 0.4 | 0.3 | 0.12 | 0.12 | 187 | 70000 | 485 | 36000 | 250 |
Olets
Weldolet Threadolet Socket Fittings
Msssp75 Olet
A105n Weldolet
We offer olets below :
Forged Weldolet , an economical butt-weld branch connection, is designed to minimize stress concentrations and provide integral reinforcement. manufactured to meet your specific reinforcement requirements.
Chemical Composition and Mechanical Property For ASTM A105
Steel Grade Chemical Composition Hardness Mechanical performance
C(Max) Mn P(Max) S(Max) Si Cu(Max) Ni(Max) Cr(Max) Mo(Max) V(Max) HB, max Tensile strength
(Min) Yield Strength
(Min)
psi Mpa psi Mpa
A105 0.35 0.6-1.05 0.035 0.04 0.1-0.35 0.4 0.4 0.3 0.12 0.12 187 70000 485 36000 250
Olets
Weldolet Threadolet Socket Fittings
Msssp75 Olet
A105n Weldolet
We offer olets below :
Forged Weldolet , an economical butt-weld branch connection, is designed to minimize stress concentrations and provide integral reinforcement. manufactured to meet your specific reinforcement requirements.
Threadolet
Threadolet utilizes the basic Weldolet configuration, provides a threaded outlet branch connection. manufactured in 3000# and 6000# classes.
Sockolet
Sockolet utilizes the basic Weldolet design configuration and incorporates a socket-weld outlet. manufactured in 3000#, 6000# and 9000# classes.
Latrolet
Latrolet , used for 45deg lateral connections, is available butt-weld to meet your specific reinforcement requirements, and 3000# or 6000# classes for socket weld and threaded applications.
MATERIAL
FORGED STAINLESS STEEL, CARBON STEEL, ALLOY STEEL
PRESSURE
3000LB, 6000LB
SIZE
1/4" TO 12"
