Tobee ® 12x10 inch salt slurry pump
- Payment Type:
- L/C, T/T, D/P, Paypal, Money Gram, Western Union
- Incoterm:
- FOB, CFR, CIF
- Min. Order:
- 1 Set/Sets
- Min. Order:
- 1 Set/Sets
- Delivery Time:
- 15 Days
- Transportation:
- Ocean, Land, Air
- Port:
- Tianjin
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | Hebei |
|---|---|
| Productivity: | 100000sets/Month |
| Supply Ability: | 100000sets/Month |
| Payment Type: | L/C,T/T,D/P,Paypal,Money Gram,Western Union |
| Incoterm: | FOB,CFR,CIF |
| Certificate: | ISO,CE,SGS,DNV |
| Transportation: | Ocean,Land,Air |
| Port: | Tianjin |
Tobee® 12x10 inch salt slurry pump are the most comprehensive range of centrifugal slurry pumps for
use in mining, minerals processing, coal preparation, dredging, metallurgy, power plant,
chemical and general industry applications. The wetted parts materials designed
by High abrasion and corrosion resistance alloy, rubber or polyurethane etc,
Expecially for handling highly abrasive,high density slurries.
SPECIFICATIONS:
Size: 1" to 22"
Capacity: 3.6-5400 m3/h
Head: 6-125 m
Handing solids: 0-130mm
Concentration: 0%-70%
Materials: Hyper chrome alloy, Rubber, Polyurethane, Ceramic, Stainless steel etc.
Tobee® 12x10 inch salt slurry pump Quick Selection Chart:
Tobee® 12x10 inch salt slurry pump Structural Design:
Metal Lined Pump
Rubber Lined Pump
No
Parts Name
Materials
No
Parts Name
Materials
1
Liner
27.5% UltraChrome Alloy
1
Frame Plate
QT500-7
2
Frame Plate
QT500-7
2
Expeller Ring
27% High Chrome Alloy
3
Frame Plate Liner Insert
27.5% UltraChrome Alloy
3
Gland Assembly
HT200
4
Cover Plate
QT500-7
4
Shaft Sleeve
420 Stainless Steel
5
Throat Bush
27.5% UltraChrome Alloy
5
Expeller
27% High Chrome Alloy
6
Impeller
27.5% UltraChrome Alloy
6
Frame Plate Liner
Rubber Coated High Tensile Steel
7
Expeller Ring
27% UltraChrome Alloy
7
Impeller
Rubber Coated High Tensile Steel
8
Shaft Sleeve
420 Stainless Steel
8
Cover Plate Liner
Rubber Coated High Tensile Steel
9
Expeller
27% HighChrome Alloy
9
Cover Plate
QT500-7
10
Bearing Assembly
SKF/Timken (Standard)
Tobee® 12x10 inch salt slurry pump Wetted Parts Design:
Tobee® 12x10 inch salt slurry pump On-site Applications:
Typical:
Mining & Mineral Processing
The slow running speeds of the Tobee TH Heavy Duty Slurry Pump, together with the comprehensive choice of
abrasion resistant alloys and elastomers, provide unrivalled performance and service life for all abrasive mining and
minerals processing applications.
Chemical Process
The interchangeability of alloy and elastomer components in the same pump casing, together with a wide range of mechanical seals,
make the Tobee TH Heavy Duty Slurry Pump the most flexible choice for the chemical plant environment.
Sand & Gravel
Designed for easy and simple strip down and re-assembly, the Tobee TH Heavy Duty Slurry Pump minimises downtime,
making it the ideal choice where installed stand by pumps are not available.
Sugar Processing
The premium reliability and service life of the Tobee TH Heavy Duty Slurry Pump is specified by many sugar plant engineers
worldwide where uninterrupted pump operation during the sugar campaign is a critical requirement.
Flue Gas Desulphurisation
The new generation of specially formulated abrasion and corrosion resistant alloys, together with the very latest
elastomer technology, positions Tobee Pumps firmly as a major supplier of pumps to the FGD industry.
Oil & Gas Exploration
Over a number of years we have developed the proven design of the Tobee TH Heavy Duty Slurry Pump ranges to
suit the specific demands of offshore applications. We can now offer the most reliable top side solution to erosive wear.
Industrial Applications
Wherever abrasive solids are causing premature failure of pumps, the Tobee TH Heavy Duty Slurry Pump range
has the right combination of performance, wear life and reliability to bring the customer the lowest cost of ownership.
