Insulating performance spiral cable cover sleeve guard

Insulating performance spiral cable cover sleeve guard

Get Latest Price

Payment Type:: L/C, T/T, D/P, Paypal, Money Gram, Western Union

Incoterm:: FOB, CFR, CIF, FCA, CPT

Min. Order:: 1000 Meter

Min. Order:: 1000 Meter

Delivery Time:: 30 Days

Transportation:: Ocean, Land, Air, Express delivery

Port:: TianJin, Qingdao, NingBo

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Hebei
Productivity:	50000 M/Month
Supply Ability:	50000 M/Month
Payment Type:	L/C,T/T,D/P,Paypal,Money Gram,Western Union
Incoterm:	FOB,CFR,CIF,FCA,CPT
Certificate:	ISO
Transportation:	Ocean,Land,Air,Express delivery
Port:	TianJin,Qingdao,NingBo

Product Description

Excellent elongation protect spiral wrap for hydraulic hoses

PRODUCT DESCRIPTION

Product advantage

1.Oil resistance: High quality qualified spiral protective sleeve has good oil resistance. The spiral protection sleeve can be soaked in 70# gasoline for 5 minutes, no discoloration, no sticking phenomenon occurs.

2 .product material surface is smooth with good wear resistance, different colors, both delicious and convenient installation.

3.Raw material PP: Has good resistance to high temperature and low temperature,Even if the winter is not brittle crack phenomenon, flexibility is good

4.Good service life: Can prolong the service life of internal products more than 3 years

Recommended For

The use of Spiral Guard Wrap is an economical and convenient method of protecting and extending the life of hydraulic and pneumatic hoses, cables, wires and rope from premature wear. Manufactured from extruded high density polyethylene (HDPE), Spiral Guard Wrap will withstand the extremes of climate and operating conditions.Spiral Guard Wrap protects against abrasion, cuts, crushing, UV and various hazards Spiral Guard Wrap's open spiral design allows for simple installation in the field, without the need to disconnect lines.

Material
high-density Polyethylene, spiral-formed protection system, wear, cut, and crush-resistant
polymer Tensile Strength 25MPa at room temperature.
Application
Mining, equipment, forestry, agriculture, trucking, automotive applications.

Hydraulic Hose Guard Application

Specifications

Item Code	I.D		Thickness	Width	Applied for
Item Code	mm	inch	mm	mm	mm
HPS-8	8	5/16"	1.5	7	8-10
HPS-10	10	3/8"	1.5	10	10-12
HPS-12	12	1/2"	1.5	12	12-14
HPS-14	14	11/20"	1.5	13	14-16
HPS-16	16	5/8"	2	15.5	16-18
HPS-18	18	3/4"	2	16	18-20
HPS-20	20	4/5"	2.2	16	20-22
HPS-22	22	43/50"	2.2	19.5	22-25
HPS-25	25	1"	2.2	22.5	25-28
HPS-28	28	1-1/10"	2.2	23	28-30
HPS-30	30	1-9/50"	2.5	23	30-32
HPS-32	32	1-1/4"	2.5	23.5	32-35
HPS-35	35	1-19/50"	2.5	24	35-38
HPS-38	38	1-1/2"	3	28	38-40.42
HPS-40	40	1-29/50"	3	28	40-42
HPS-42	42	1-13/20"	3.5	28	42-45
HPS-45	45	1-39/50"	3.5	28	45-50
HPS-50	50	2"	3.5	28	50-60
HPS-60	60	2-1/2"	4	28	60-74
HPS-74	74	2-9/10"	4	46.5	74-80
HPS-80	80	3-3/20"	4.5	48.5	80-88
HPS-88	88	3-1/2"	4.5	50	88-100
HPS-100	100	4"	4.5	57	100-130
HPS-130	130	5"	4.5	50	130-155
HPS-150	150	6"	4.5	50	150-200
HPS-200	200	7-22/25"	5	50	200

OVERALL SHOWING

ORIENTFLEX

Factory History: Established in 2006
Business Type: Manufacturer and exporter
Main Products: Small machinery such as hydraulic hose crimping machine, industrial hose, hydraulic hose, PVC hose and hose coupling.
