portable rebar threading machine

Get Latest Price

Quantity:

Your message must be between 20 to 2000 characters

Contact Now

Basic Info

Place of Origin:	Hebei, China (Mainland)

Product Description

Portable rebar threading machine is use for Cutting External Thread on Rebar by Chasing method. HSS Rebar Threading Tangential Chasers are use as cutter. Rebar remains stationery and Die Head rotates. Matric, BSP, BSPT, NPT, UNF,UNC, BSW, Acme Threads B.S.F etc. threads can be cut on this rebar threading machine depending upon the type of Rebar Threading Chasers. The portable rebar threading machine mainly consists the following:-
* Base
* Head Stock
* Saddle
* Bed or Pillar Type Clamping Vice
* Die Head.

1.Main Techincial Parameter:

1.Voltage:3-380V 60Hz

2.Motor Power:4.0KW

3.The Max Thread Length:200mm/300mm(Customized by customers request)

4.Spindle Speed:40-62R.P.M

5.Thread Angle:55/60/75 degree

2.Features:

1) Peel the rebar ribs and process threads on rebar end in one procedure.

2)Left-handed and Right-handed thread can be processed.

3)Simple operation, good quality, realiable working, and high efficiency.

4)Rebar dia for 14-40mm can be adjusted by position disc.

Types of Rollers	Big	Middle	Small
Dia of Rebar Processing	14-22	25-32	36-40
Thread Pitch	2.5	3.0	3.5

3.Machine Advantages:

Simple operation; saving material; reducing cost; Shortening construction period, reduce the labor intensity of workers.

4. Specification Data

Capacity	Model NCT-1.1/2"	Model NCT-2.1/2"
Saddle Movement	12"-14"	14" - 16"
Spindle Speed Range	60-90	60-90
Number of Spindle Speed	2	2
Threading Capacity	3/8" to 1.1/2"	1/2" to 2.1/2"
Production per Hour	60-80	60-80
H.P. Required	3 H.P. 960 RPM	7.5 H.P. 960 RPM
Lead Screw	N.A	N.A
Weight (KG)	550	990

5. Company Tradition:

DESIGN & WORKMANSHIP: The DIAMOND Rebar thread cutting machine are designed to produce quality threads within the to lerance for which they were intended.

HEAD STOCK: A heavy duty geared Head Box is of best quality casting providing support to the spindle bearings. The box is of gear type, lubricated, fitted with three extra heavy duty bearings.

THE BED: The bed is pillar type having two pillars made of best quality steel nicely finished & duly hard chrome plated in the most modern hard chrome plating unit.

THE SADDLE: The Saddle is fitted on two pillers very precisely. It runs on pillars very smoothly and accurately to the Head Stock alignment.

The APRON: The apron gives movement to the saddle with head transfer along with pillars through steel rack and pinion arrangements. It's all gears are made of best quality steel.

VICE JAWS: The vice jaws made from the best quality alloy steel are fitted on the saddle well aligned with the head stock center fitted in a heavy duty box type vice. The jaws are heat treated. The movements of jaws are controlled by a screw on the saddle.

Range of NCT Threading Machines and Die Heads.

1/4" to 1" do/-
3/8" to 1.12" do/-
1/2" to 2.1/2" do/-
