SMSPR65-QV Rubber Sump Pump

SMSPR65-QV Rubber Sump Pump

• Product Introduction

Interchangeability of hard metal and rubber parts provides the best solution for each individual application. SPR sump slurry pump is rubber lined SP series slurry pump. Standard SMSPR65-QV rubber sump pump is supplied with parts in wear resistant natural rubber. Natural rubber is resilient when impacted by suspended particles in slurry mixtures. High-quality natural rubber has excellent abrasion resistance. This rubber lined long shaft sump slurry pump is available for handling the finer particle slurries to obtain long operating life.

• Type Notation:

 For example: SMSP(SPR)150-SV(L) (SP: SP series Sump Pump; SPR: Rubber Lined Sump Pump;150: Discharge Diameter (mm); SV: Frame Type; L: Extension Type.)

• Product Feature

1. The single-casing sump slurry pump`s impeller is open structure, built from natural rubber.

2. Heavy duty roller bearings, above mounting plate.

3. Vertical, centrifugal and single-casing structure.

4. No submerged bearings.

5. No shaft sealing problems.

6. Direct drive, V-belt drive, variable frequency drive for pump could be selected to connect with the driver.

• Range of Performance

Capacity     22.5~105m3/h

Head         5.5~30.5m

Discharge diameter: 65mm

•  Drive Type

 • Type Of Pump Inlet Construction

• Performance Curves

• Outline Drawing
