Description

A new generation of S-band Doppler weather radar antenna and S-band 8.5m diameter Doppler weather radar antenna were produced more than 100 sets totally, and C-band 8.5m diameter dual-polarization weather radar antenna is also available.

Weather radar antenna

Performance index of antenna servo system in S band with single polarization.

Series No.	Item	Performance requirements
1	Aperture	8.5m
2	Working frequency	2.70GHz~3.00GHz
3	Beam width	≤0.99°
4	Gain	≥44.5dB
5	Polarization mode	· Horizontal line polarization
6	First sidelobe level	≤-29dB;wide angle sidelobe:±2°~10°:located below -29dB~-38dB connection line;±10~90°:≤-42dB
7	Voltage to standing wave radio	≤1.45
8	Rotation range	360° continuous rotation; pitch -1° to +90° continuous rotation.
9	Rotation speed	Azimuth 0°~36°/s; pitch 0°~36°/s.
10	Speed accuracy	Azimuth, pitch ≤±5%
11	Angle acceleration/deceleration speed	Position, pitch: 15°/S2~19°/S2
12	Position error	Azimuth and pitch ≤±0.1o

Airborne X band radar antenna

Performance index

Series No	Item	Indicator capacity
1	Working frequency	X band
2	Beam forming range	Pitch 45° cosecant squared
3	Polarization	vertical
4	Gain	≥ 23dB
5	Sidelobe level	≤ -20dB
6	Antenna weight	≤ 10Kg
7	Antenna volume	≤400mm×600mm×60mm
8	Working temperature	-55℃~75℃
