five heddle stainless steel wire mesh
- Min. Order:
- 10
- Min. Order:
- 10
Your message must be between 20 to 2000 characters
Contact Now| Place of Origin: | China |
|---|---|
| Supply Ability: | 5000rolls/month |
Five heddle twilled weave specification
|
Standard No |
Wire diameter |
Micro retention |
Weight in kg |
Thickness In mm |
Flowratings |
||||
|
Warp Per 25.4mm |
Weft Per 25.4mm |
Warp In mm |
Weft In mm |
abs. μm |
nom. μm |
Water l/cm2h*200mbar |
Air Nm3/h*20cm 2/2mbar |
||
|
132 |
85 |
0.140 |
0.200 |
0.09-0.11 |
0.052 |
1.47 |
0.44 |
402 |
17.30 |
|
107 |
132 |
0.160 |
0.140 |
0.055-0.065 |
0.055 |
1.30 |
0.44 |
424 |
19.80 |
|
107 |
125 |
0.160 |
0.140 |
0.065-0.08 |
0.070 |
1.27 |
0.45 |
480 |
23.90 |
|
107 |
59 |
0.160 |
0.160 |
0.16-0.18 |
0.077 |
1.09 |
0.45 |
995 |
46.00 |
|
80 |
60 |
0.200 |
0.200 |
0.20-0.22 |
0.127 |
1.40 |
0.55 |
1056 |
39.80 |
|
77 |
40 |
0.240 |
0.240 |
0.38-0.40 |
0.095 |
1.65 |
0.68 |
1022 |
42.90 |
|
65 |
36 |
0.300 |
0.300 |
0.26-0.29 |
0.100 |
2.27 |
0.84 |
996 |
48.50 |
|
55 |
36 |
0.300 |
0.300 |
0.25-0.28 |
0.175 |
2.05 |
0.84 |
900 |
40.20 |
|
48 |
45 |
0.400 |
0.400 |
0.17-0.21 |
0.130 |
3.79 |
1.11 |
1080 |
49.90 |
|
48 |
45 |
0.290 |
0.290 |
0.24-0.26 |
0.230 |
2.00 |
0.83 |
1135 |
49.50 |
|
48 |
25 |
0.300 |
0.300 |
0.46-0.50 |
0.250 |
2.73 |
0.82 |
1164 |
54.00 |
|
30 |
18 |
0.500 |
0.500 |
0.60-0.65 |
0.370 |
3.00 |
1.48 |
1200 |
63.00 |
|
28 |
17 |
0.470 |
0.470 |
0.75-0.80 |
0.460 |
2.53 |
1.41 |
1400 |
64.20 |
|
24 |
20 |
0.600 |
0.600 |
0.65-0.75 |
0.490 |
3.96 |
1.70 |
1254 |
57.10 |
|
15 |
13 |
0.900 |
0.900 |
1.15-1.20 |
0.850 |
5.67 |
2.60 |
1284 |
60.30 |
Usage :mainly used in copy making sanitary paper, cultural paper, packing paper, filter gas, liquid and other medium
